C2 base 12 PPC
C2 base panel PCs: Máy tính bảng công nghiệp tiết kiệm chi phí
|
12.1" Panel PC- 12.1" 1280 x 800 pixel (16:10) TFT-LCD - Projected capacitive touch screen - Intel® 7th generation Dual Core™ Celeron® 3965U (2 x 2.2GHz) - Main memory 4GB DDR4, application memory 256GB - Windows® 10 IoT Enterprise - CE and UL approvals |
Thông số
General description
Part number | 100-1175 |
Life cycle status | Mature |
Warranty | 2 years |
Certifications
General | CE, UL, cUL |
Mechanical
Mechanical size | 316 x 228 x 85mm |
Mounting option | Panel mount |
Touch type | Capacitive type |
Cut-out size | 303 x 216mm |
Weight | 5.0kg |
Housing material | Anodized aluminium front, zinc plated steel sheet back |
Power
Input voltage | +24VDC (18 - 30VDC) |
Power consumption (max) | 60W max. |
Input fuse | Internal DC fuse, 5A slow |
System
CPU | Intel® Celeron® 3965U |
RAM | 4GB DDR4 |
FLASH | 256GB SSD 2,5" industrial-grade SSD |
Display
Size diagonal | 12.1" diagonal |
Resolution | 1280 x 800 pixel |
Backlight | LED backlight |
Backlight life time | > 100000h |
Backlight brightness | 500cd/m² |
Display type | TFT-LCD |
Display ports | 1 x HDMI, 1 x DP |
Ethernet communication
Number of Ethernet ports | 2 |
Ethernet port 1 | 1GB RJ45 |
Ethernet port 2 | 1GB RJ45 |
Expansion interface
USB | 4 x USB3.0 900mA |
Environmental
Operating temperature | 0°C - +50°C |
Storage temperature | -20°C - +70°C |
Shock | 15G 11ms (half sine) |
Vibration | 1g 10-500Hz 3 axis |
Sealing front | IP65 |
Sealing back | IP20 |
Humidity | 10% - 90 % non condensing |
Altitude (max) | < 3000m |
