C2 base 15 iX

C2 base 15 iX
Lượt xem: 401
  • Thông tin chi tiết
  • Bình luận

C2 base 15 iX

C2 base PPCs with iX: PCs công nghiệp tiết kiệm chi phí






   15.6" Panel PC

- 15,6" 1920 x 1080 pixel (16:9) TFT-LCD

- Projected capacitive touch screen

- Intel® 7th generation Dual Core™ Celeron® 3965U (2 x 2.2GHz)

- Main memory 4GB DDR4, application memory 256GB

- Windows® 10 IoT Enterprise

- CE and UL approvals

Thông số

General description

Part number 100-1083
Life cycle status Mature
Warranty 2 years

Certifications

General CE, UL, cUL

Mechanical

Mechanical size 432 x 281 x 74mm
Mounting option Panel mount
Touch type Capacitive type
Cut-out size 413 x 262mm
Weight 6.7kg
Housing material Anodized aluminium front, zinc plated steel sheet back

Power

Input voltage +24VDC (18 - 30VDC)
Power consumption (max) 60W max.
Input fuse Internal DC fuse, 5A slow

System

CPU Intel® Celeron® 3965U
RAM 4GB DDR4
FLASH 256GB SSD 2,5" industrial-grade SSD

Display

Size diagonal 15.6" diagonal
Resolution 1920 x 1080 pixel
Backlight LED backlight
Backlight life time > 50000h
Backlight brightness 300cd/m²
Display type TFT-LCD
Display ports 1 x HDMI, 1 x DP

Ethernet communication

Number of Ethernet ports 2
Ethernet port 1 1GB RJ45
Ethernet port 2 1GB RJ45

Expansion interface

USB 4 x USB3.0 900mA

Environmental

Operating temperature 0°C - +50°C
Storage temperature -20°C - +70°C
Shock 15G 11ms (half sine)
Vibration 1g 10-500Hz 3 axis
Sealing front IP65
Sealing back IP20
Humidity 10% - 90 % non condensing
Altitude (max) < 3000ma
